General Granulator
Category：
Advantage & Benefit
Features
The blade design is reasonable, the product is evenly granulated
The gap between the moving and fixed blades is adjustable
General-purpose granulator adopts a sealed bearing which allows high durability
Benefit
Energy-saving and durable, efficient and economical
Equipped with multiple safety protection devices to ensure safe operation.
The finished product is uniform, power saving and durable
Technical Specifications
| Model |
Crushing Chamber (mm) |
Throughput(kg/h) | Fixed Blade(pcs) | rotary blade(pcs) |
Power(hp) |
Screen Doening (mm) |
Dimension L x W x H (cm) |
From Feed Hopper to the Ground H1(cm) |
Net Weight (kg) |
|
| KW | HP | |||||||||
| WSGP-230 | 230×215 | 100-150 | 2 | 6 | 4 | 5 | 8 | 97×61×120 | 120 | 290 |
| WSGP-300 | 310×200 | 150-200 | 2 | 9 | 5.5 | 7.5 | 8 | 100×72×129 | 100 | 435 |
| WSGP-400 | 410×235 | 200-250 | 2 | 12 | 7.5 | 10 | 8 | 103×84×139 | 104 | 500 |
| WSGP-500 | 515×290 | 300-350 | 2 | 15 | 11 | 15 | 8 | 123×101×163 | 123 | 900 |
| WSGP-600 | 610×320 | 350-450 | 4 | 18 | 15 | 20 | 8 | 132×111×183 | 137 | 970 |
| WSGP-800 | 815×470 | 450-600 | 4 | 24 | 22/30(Optional) | 30/40(Optional) | 10 | 173×149×320 | 172 | 2000 |
| WSGP-960 | 960×610 | 600-800 | 4 | 12 | 37/55(Optional) | 50/75(Optional) | 12 | 258×176×268 | 204 | 3000 |
Application Scenarios
Pipe
Profile
Plate
Sprue
Previous
Next
Previous
Next
FAQ
What is a granulator and what type of material is fed into it how is the regrind used?
A granulator is specifically used in plastic processing for size reduce plastic lumps into plastic flakes, resin or regrind. Granulators are used to reduce runners and scrap back to pellet size pieces that blend back in with virgin resins. Granulator is also known as crusher or grinder.
How do you turn plastic into granules?
The process involves cutting plastic scraps into small pieces and heating them until they melt. The molten plastic is then passed through a die, which produces cylindrical pellets. These pellets can be reused as raw material in manufacturing plants, thereby reducing raw material costs.
What are granulators used for?
Granulators are essentially rotary grinders that are used to grind scrap parts and melt delivery systems (sprues and runners) into feedstock sized granules for reprocessing. This allows the molder to reduce waste and produce components more cost effectively.
What is a plastic granulator?
A Plastic Granulator is a machine used for breaking down plastic products for Recycling. These machines come in a variety of types for industries and workshops and the various sizes of plastic products.
